- Size: 4
- Place of Origin: china
- Brand Name: ELK
- Model Number: LD-10Ton
- Weight: 5000.000 kg
| Main girder | Material Q235B, thickness:5-6mm Stong but light, beautiful appearance, long service life. Can be operation outdoor. If the span is over 12m, we suggest cut it in two parts for convenient to delivery. After you receiving it, you can adopt point-welding method, and then use the bolts and nuts provided by us, to make two parts together. |
| Electric hoist | Electric hoists are featured products, includes electric chain hoist, electric wire rope hoist. If your workshop is limited, we can also adopt low headroom type. Any special requirement, do not mean to tell us, we will provide the suitable for you according to your requirement. |
| End carriage | We produce end carriage by ourself, including motor and wheel, not purchasing outside. We adopt reduction gear motor with buffer, which is with electromagnetic brake, soft starting, also easy heat dissipation, low noise and high security, to make sure girder operate on rails smoothly and safely |
| Rail | If within 3ton, adopt P18, if more than 3tons, adopt P24, according to exact capacity. |
| H-beam | One piece length is 6m, if the capacity is within 5ton, adopt 350mm*175mm |
| Electric and hanging system | Includes no joint security slide wire, collector, comealong ( power supply, installed on rails, which is concise appearance.If outside, suggest to adopt enclosed bus bar), flat cable,thin cable, cable trolley and accessories, C-type steel, electric control case. |
- Size: 4
- Place of Origin: china
- Brand Name: ELK
- Model Number: LD-10Ton
- Weight: 5000.000 kg
| 1t single girder overhead crane | End carriage |
| Span: less than 7.5M | End carriage DGTC-1.5-150 (Lengh:1500mm,Dia. of wheel 150mm, motor Power:0.4Kw) |
| Span: 7.5M-11.5M | End carriage DGTC-3.0-150 (Lengh:2000mm,Dia. of wheel 150mm, motor Power:0.4Kw) |
| Span:12M-13.5M | End carriage DGTC-2.5-180 (Lengh:2500mm,Dia. of wheel 180mm, motor Power:0.4Kw) |
| Span:14M-16.5M | End carriage DGTC-3.0-180 (Lengh:3000mm,Dia. of wheel 180mm, motor Power:0.4Kw) |
| Span:17M-22.5M | End carriage DGTC-3.5-200 (Lengh:3500mm,Dia. of wheel 200mm, motor Power:0.4Kw) |
