Product Details
- Size: 2
- Place of Origin: China
- Brand Name: ELK
- Model Number: 150427-85
- Weight: 300.000 kg
| Brake system | The brake is equipped with an automactic adjusting device to apply brake torque in proportion to the amount of lining abrasion, the auxiliary brake ensure hoist safe when then main brake stop working. |
| Thermal protector | As customer required, we will adopt thermal protector inside of hoist, hoist motor will automatically stops when sensing the heat of motor coil in order to protect the motor from burning damage caused by heat due to overwork |
| Gear | Reprocessing makes gear high precision. |
| Control box | Adopt Schnerider A.C.contactor, and well-know other brands electric parts. |
| Hooks | Strong and safe |
| ISO | M4 /FEM: 1AM(M5 customized available) Insulation grade: F |
| Protection class | hosit :IP54,or IP 55;push button:IP65 |
| Noise | 81dB. |
- Size: 2
- Place of Origin: China
- Brand Name: ELK
- Model Number: 150427-85
- Weight: 300.000 kg
| Type | Capacity (ton) | Standard Lifting Height (m) | Lifting Speed (m/min) | Lifting Motor | Trolley Motor | ||||
| Power (Kw) | Phases | Voltage (v) | Frequency (Hz/s) | Power (Kw) | Trolley speed (m/min) | ||||
| HKDS0102 | 1 | 6/12/18/24/30 | 11 | 2.5 | 3 | 200-600 | 50 | 0.4 | 21 |
| HKDS0202 | 2 | 6/12/18/24/30 | 8.4 | 2.5 | 3 | 200-600 | 50 | 0.4 | 21 |
| HKDS0204 | 2 | 6/12 | 4.2 | 2.5 | 3 | 200-600 | 50 | 0.4 | 21 |
| HKDS0302 | 3 | 6/12/18/24/30 | 7.5 | 6 | 3 | 200-600 | 50 | 0.75 | 21 |
| HKDS0304 | 3 | 6/12 | 3.75 | 6 | 3 | 200-600 | 50 | 0.75 | 21 |
| HKDS0504 | 5 | 9/12/18 | 6.7 | 7.5 | 3 | 200-600 | 50 | 0.75 | 21 |
| HKDS07504 | 7.5 | 9/12 | 6 | 9.5 | 3 | 200-600 | 50 | 0.75*2 | 21 |
| HKDS1004 | 10 | 9/12 | 5 | 11 | 3 | 200-600 | 50 | 0.75*2 | 21 |
| HKDS1504 | 15 | 9/12 | 4 | 8*2 | 3 | 200-600 | 50 | 0.75*2 | 21 |
| HKDS2004 | 20 | 12 | 3 | 9*2 | 3 | 200-600 | 50 | 0.75*2 | 21 |
